The MPO connector is a type of fiber connecter. MPO (Multi-Fiber Push On) is a multi-core fiber connecter type. The MPO high -density fiber pre -connection system is currently mainly used in the application of high -density environments of data centers, the application of optical fiber to the building, and the internal connection applications inside the optical transceiver equipment such as the optical device, 40G, 100G, QSFP+.
Premium MPO Fiber Cable | High density & low loss
Reliable quality, full testing, custom specs & OEM available
Professional technical support and global after-sales service
● Product origin: China
● Delivery time: 7 -10 workdays
We are the manufacturer that could support you with good quality at an aggressive price. We are the best choice for you among many traders and resellers. Feel free to send us any of your questions and inquiries, we would be more than pleased to send you more information.
| Spec items. | Single mode (APC 8-degree polished) | Multimode (PC Flat polish) |
|---|---|---|
| Insertion loss (MPO) (IEC 61300-3-34) |
Standard loss: ≤0.75dB(max), ≤0.50dB(Typical) Super Low loss: ≤0.35dB(max), ≤0.20dB(Typical) |
Standard loss: ≤0.6dB(max), ≤0.50(Typical) Super Low loss: ≤0.35dB(max) , ≤0.20dB(Typical) |
| Insertion loss (LC/SC/FC/ST) (IEC 61300-3-6) |
≤0.3dB | ≤0.3dB |
| Return loss(MPO) | ≥60dB（8degree polishing） | ≥25dB |
| Return loss(LC/SC/FC/ST) | APC≥60dB; UPC≥50dB | ≥35dB |
| Durability | <0.3dB typical change, 200 matings | |
| Interchangeability | ≤0.2dB | |
| Plug-in times | ≤ 500 | |
| Tensile strength | >70N | |
| Operating Temperature (°C) | -40 to + 85°C | |
We provide full customization, including 8/12/24/48-core configurations, OM3/OM4/OS2 fiber types, LSZH/PVC jacket options, and custom lengths, backed by strict quality testing and global certification compliance. Whether for data center backbone cabling, high-speed server interconnection, or long-distance telecom transmission, our MPO fiber cables deliver a future-proof, cost-effective solution for your network infrastructure.
Q1: What is an MPO fiber patch cable?
A1: An MPO fiber patch cable is a high-density multi-fiber cable assembly designed to connect MPO/MTP interfaces in data centers. It is commonly used for 40G/100G/200G/400G backbone connections and structured cabling systems.
Q2: What is the difference between MPO and MTP?
A2: MTP is a premium brand version of the MPO connector (developed by US Conec) with improved mechanical performance, better alignment accuracy, and more stable insertion loss. MTP connectors are fully compatible with standard MPO interfaces.
Q3: Can MPO patch cables support 400G networks?
A3: Yes. MPO patch cables are commonly used in 400G deployments, especially for QSFP-DD or OSFP transceivers (SR8 / DR4 / FR8 applications).
Q4: What is MPO fiber cable mainly used for?
A4: Typical insertion loss standards for high-quality fiber patch cords are:
